What to do if the gas pipeline is far from the gas stove? How to transform the gas pipeline far from the gas stove

We all know that many people will encounter various problems when decorating their houses. One of the more common problems is that the gas pipeline is far away from the gas stove. Many people will encounter this situation. So what should we do if the gas pipeline is far away from the gas stove? Let's take a closer look!

What to do if the gas pipeline is far from the gas stove

There are generally two ways to deal with the gas pipeline being far from the gas stove: one is to change the gas pipeline, the other is to change the location of the stove.

Modification of gas pipes

To modify the gas pipeline, the gas company must do the modification. You cannot modify it yourself. Doing so is illegal. Gas pipelines are generally metal pipes with good anti-corrosion treatment. You can apply to the gas company for modification, inform the modification distance and pipeline direction, and the gas company will do the construction and inspection.

The pipeline usually goes from the cabinet floor to the stove. Before renovation, it is necessary to make a valve at the pipeline mouth. It is recommended that the pipeline mouth is located farther away from the cabinet partition, so that it is convenient to install the pipe from the pipeline mouth to the stove later, or to replace the hose during maintenance. The pipeline mouth is placed in the cabinet below the stove for easy operation.

One way is to run the pipe against the upper part of the cabinet and against the wall, and the other way is to run it under the bottom plate of the cabinet. Both methods are acceptable. Just don't seal the pipe. As for later maintenance, it is generally better to run it inside the cabinet, although this takes up a certain amount of cabinet space and requires drilling holes in the cabinet partition.

Another way is to use a stainless steel bellows, which is suitable for changes within 3 meters, preferably within 2 meters. You don't need to find a gas company, you can buy and install it yourself, and you can also use a hose within 2 meters. This distance refers to the distance between the gas pipeline opening and the stove air inlet.

Changing the position of the stove

Changing the exhaust pipe means changing the position of the stove and moving it closer to the gas pipe opening. Generally, the stove is installed close to the exhaust pipe. If the stove is far away from the gas pipe opening, you can change the position of the stove and extend the exhaust pipe for decoration. The exhaust pipe cannot be too long, otherwise the exhaust effect will be poor. Generally, it is 2-3 meters, and the stove can be moved 2-3 meters.

Consider the decoration according to the on-site conditions and combine the above two methods. If the distance is short, it is more cost-effective not to apply for renovation by the gas company. Applying for renovation by the gas company is more expensive and takes up space, but it is safer.

How to modify the gas pipeline if it is too far from the gas stove

Drill a hole through the cabinet

Generally, the gas stove is too far away from the gas. If it is a U-shaped cabinet, you can drill a hole in the cabinet and pass the pipeline to the side of the gas stove. In this way, the pipeline will definitely be much longer, which is relatively reasonable and beautiful.

Before laying tiles, cut a groove in the wall to run the pipes

In this case, a thicker pipe is needed, at least more than five centimeters. Do not use a pipe that is too thin, otherwise the gas pipe may not be able to pass through. Make elbows on both sides of the pipe, and the angle of the bend should not be too straight, as it is not good for the gas pipe. This is also very beautiful, but the pipe inside needs to be replaced every six months or a year. Be sure to use the best pipe, safety first.

From the kitchen top

The pipe required to run through the kitchen ceiling will be longer, and the gas usage effect is not very good, so it is not recommended. However, running through the ceiling is convenient for maintenance, because most kitchens have integrated ceilings and are easy to disassemble. However, the pipe will definitely be exposed near the junction with the gas stove, which does not look good.

Contact the gas company to change the pipeline

This method is still better, but generally gas companies do not recommend changes, but sometimes they can change the pipelines that really need to be adjusted, such as moving the gas pipeline up and down, if it is difficult to change the position. But some can also be changed, and coordination is required.

Summary: If the gas pipeline is too far from the gas stove, you can try the above four methods. You can drill a hole in the floor cabinet to pass the gas pipeline, or you can run the pipeline in the wall, or you can run it through the kitchen ceiling. However, the pipeline is too long. Finally, you need to contact the gas company to coordinate the modification of the pipeline.

Decoration suggestions for gas pipes far from gas stoves

First of all, the main pipeline cannot be dismantled without permission. Only add commonly used explosion-proof pipes under the main pipeline with a valve, and then connect the 3-meter or 5-meter explosion-proof pipe with a knot according to the distance from the stove until it is connected to the stove. Be sure to remember to add a sealing gasket at the knot to ensure that there is no leakage before use.

If the distance is short, within 2 meters, you can use a cowhide hose. If the distance is more than 2 meters, you generally need to use a stainless steel corrugated pipe. Gas stoves and gas water heaters should use 4-point pipes. Wall-mounted boilers use 6-point pipes. This kind of stainless steel glass pipe is usually installed by the gas company, or by the store that sells gas water heaters or wall-mounted boilers.

You can contact the gas company to purchase an extended stainless steel gas pipe, or measure the size and purchase it online and install it yourself. The gas pipe joints are universal. When installing it yourself, please close the gas valve and pay attention to safety.
